Shielded RJ45 Modular Jack with Integrated Ethernet Filter for 100Mbps Network Applications

Type : Multi pin rj45 magjack

Place of Origin : DongGuan of China

operation temperature : -40°C~+85°C

Model Number : DGKYD411B242DE3A1DP

Plating : Glod plating 6u/15u/30u/50u

MOQ : 1 piece

Delivery Time : 10 days

Product Name : RJ45 Modular Jack

Payment Terms : T/T,D/P,D/A,L/C,Western Union,MoneyGram

Feature : Shielded RJ45 network port

Gender : rj45 receptacle

Price : Please contact us to get the latest price.

OEM/ODM : yes

Supply Ability : 100K pcs/day

Application : fiber optic,ip camera ,dvr,dsl,modem,wifi etc

Housing Material : PBT Black

Packaging Details : Tray in Carton

Certification : RoHS/CE/UL/FCC/CE/ISO9001/ISO14001

Brand Name : DGKYD

LED Color : Green/Green-Yellow

storage temperature : -40°C~+85°C

Contact Now

RJ45 Network Socket POE 100Mbps Integrated Ethernet Filter Computer Connector DGKYD411B242DE3A1DP

RJ45 network socket with Power over Ethernet (POE) capability, 100Mbps integrated Ethernet filter computer connector. Part Number: DGKYD411B242DE3A1DP

Download Product Documentation (PDF)
Technical Parameters
Parameter Specification
Part Number DGKYD411B242DE3A1DP
Brand DGKYD/OEM/ODM
Product Type Connector-Modular
Connector Style Jack
Jack Type RJ45
Connector Type Modular Jack
Latch Style Standard
Latch TAB-UP
Filter With Filter
LED Option With LED
LED Color Green/Green-Yellow
Panel Stops With Panel Stops
Shielded With metal shield
Applies To Printed Circuit Board
Port Configuration Single Port
Number of Positions 12
Jack Configuration 1X1
Terminals per Port 8
Shield Material Copper Alloy preplated with Nickel
PCB Mounting Orientation Side Entry (Right Angle)
Contact Mating Area Plating Gold 6u
Contact Base Material Phosphor Bronze
Solder Tail Contact Plating Material Tin-Lead over Nickel
PCB Mounting Style Through Hole
Termination Method to PC Board Through Hole-Press-Fit
Board Lock With/Without Board Lock
Housing Material PBT Polyester
Housing Color Black
Housing Material Temperature Standard
UL Flammability Rating UL 94V-0
Product Images
Shielded RJ45 Modular Jack with Integrated Ethernet Filter for 100Mbps Network Applications Shielded RJ45 Modular Jack with Integrated Ethernet Filter for 100Mbps Network Applications Shielded RJ45 Modular Jack with Integrated Ethernet Filter for 100Mbps Network Applications Shielded RJ45 Modular Jack with Integrated Ethernet Filter for 100Mbps Network Applications Shielded RJ45 Modular Jack with Integrated Ethernet Filter for 100Mbps Network Applications Shielded RJ45 Modular Jack with Integrated Ethernet Filter for 100Mbps Network Applications Shielded RJ45 Modular Jack with Integrated Ethernet Filter for 100Mbps Network Applications Shielded RJ45 Modular Jack with Integrated Ethernet Filter for 100Mbps Network Applications Shielded RJ45 Modular Jack with Integrated Ethernet Filter for 100Mbps Network Applications Shielded RJ45 Modular Jack with Integrated Ethernet Filter for 100Mbps Network Applications
Technical Specifications
  • Interface Type: RJ45 connector for 10/100/1000BASE-T Ethernet
  • Type: RJ45 with built-in magnetics
  • Working Frequency: High frequency with filtering and anti-interference characteristics
  • Working Temperature: -40°C to 85°C
  • Storage Temperature: -40°C to 85°C
  • Lead-Free Soldering: Wave soldering height up to 265°C
Manufacturing Capabilities

RJ45 full series of integrated circuit accessories, manufacturer direct supply

  • Business Mode: Manufacturer
  • Delivery Time: Approximately two weeks for standard orders
  • Customization Options:
    • LED indicator light (green, yellow, red, orange, blue, bi-color LED)
    • Shield with EMI fingers or without
    • Coil ratio of magnetic core
    • Magnetics circuit diversification options
    • Contact gold plating (FU, 3U, 6U, 15u, 30U, 50U)
    • Plastic housing material (PBT, PA46, PA9T, LCP)

Our products meet industry standards for electrical properties, mechanical dimensions, and environmental compliance. Your satisfaction is our primary service objective!

Frequently Asked Questions
Q: Are you a trading company or manufacturer?
A: We are a manufacturer. Welcome to visit our factory.
Q: What about your lead time?
A: For products in stock, delivery within 5-7 working days after payment. For customized and out-of-stock products, delivery time is confirmed based on order quantity.
Q: Can you provide samples? Are they free?
A: Yes. We typically provide 2-3 samples of standard products free for testing purposes.
Q: Can I put my own logo on it?
A: Yes. As a manufacturer with 11 years of OEM experience, we are fully capable of customizing products to your specifications.
